SHURflo 4048 12v Rv High Flow Fresh Water Pump

SHURFLO? 4048 High

Flow Pump

With flow reaction technology, SHURFLO?’s HIGH FLOW fresh water pump has a unique one-piece diaphragm and internal by-pass to assure smooth flow, long life and top performance in any plumbing system. Designed and built for high flow, low noise, smooth flow with no rapid cycling and SHURFLO? reliability, this fresh water demand pump is quiet and can run dry without damage. Mounts in any position. This pump is designed to replace both the 4900 and 5900 Smart Sensor series products.



FEATURES

4 Gallons per Minute

55 PSI, 10 Amps Max, High Performance

Reduced Cycling with Flow Reaction Technology?

Smooth, High Powered Flow

Runs Dry ? Thermally Protected

Self-Priming to 6 Vertical Feet

Internal Bypass-Low Cycling

Built-In Check Valve Prevents Back Flow



SPECIFICATIONS

Model Numbers OEM/Aftermarket  –  4048-153-A75, 4048-153-E75

Voltage  –  12 VDC

Dimensions –  10.3? x 4.9? X 4.8? [260 x 125 x 122mm]

Flow Rate –  4.0 GPM [15 LPM]

Amps (Max.)  –  10

Shut-Off Pressure  –  55 PSI [3.8 BAR]
